Mosquito Dowel Bits with solid carbide body

Product

Drawing

  • Solid Tungsten Carbide
  • MAN

Article

Description

Machine / Application

  • portable boring machines
  • automatic boring machines
  • CNC machining centers
  • for chip-free drilling of dowel holes in solid woods and wood-based panels

Design

  • special cutting edge geometry
  • 2 spurs
  • centering point
  • boring part made from fine-grain solid tungsten carbide

Advantages

  • chip-free hole edges thanks to special cutting edge geometry with spurs
  • safe drilling thanks to centering point
  • high feed rates and edge lives increased up to sixfold compared to traditional dowel bits thanks to solid carbide design
  • high process safety thanks to constant quality of the bores for a long time

Notes

  • adjusting screw Ident-No. 001600 M5x10 DIN 551 included in delivery
  • through-hole bit with shank length L3=22 mm is not suitable for Weeke adjusting screw
  • adjusting screw Ident-No. 186017 M5x11,5 for Weeke must be ordered separately
  • clamping elements: combi chuck, quick-change chuck

Table- and picture caption ...

Ø D
[mm] 		L2
[mm] 		Ø d
[mm] 		L3
[mm] 		L1
[mm] 		Z L/R Ident-No. Comp./ Inqu.

Dimensions entered are not listed?
Please contact our application consulting .

available from stock
available on short notice
Delivery time on request

3 9,0 10 35 57.5 2+2 R 183142
|
3 9,0 10 35 57.5 2+2 L 183143
|
3 18 10 31 57.5 2+2 L 182380
|
3 18 10 31 57.5 2+2 R 182381
|
4 20 10 29 57.5 2+2 L 182382
|
4 20 10 29 57.5 2+2 R 182383
|
5 22 10 27 57.5 2+2 L 182384
|
5 22 10 27 57.5 2+2 R 182385
|
6 22 10 25 57.5 2+2 R 183144
|
6 22 10 25 57.5 2+2 L 183145
|
8 22 10 25 57.5 2+2 R 183146
|
8 22 10 25 57.5 2+2 L 183147
|
3 18 10 43.5 70 2+2 L 182386
|
3 18 10 43.5 70 2+2 R 182387
|
4 30 10 31.5 70 2+2 L 182388
|
4 30 10 31.5 70 2+2 R 182389
|
5 30 10 31.5 70 2+2 L 182390
|
5 30 10 31.5 70 2+2 R 182391
|
6 30 10 30 70 2+2 R 183148
|
6 30 10 30 70 2+2 L 183149
|
8 35 10 22 70 2+2 R 183150
|
8 35 10 22 70 2+2 L 183151
|
