SetProfiler set - planing

Product

Drawing

  • Tungsten Carbide [HW]

Article

Description

Machine / Application

  • molders
  • for use in profile cutterheads with serration

Design

  • n max = 12,000 min-1
  • cutting material: HW
  • HL Solid 30 topline for hard and soft woods
  • HW topcoat
  • topline (polished face)

Advantages

  • significantly improved cutting edges
  • excellent cutting quality
  • compared to uncoated HW-Blanks the edge lives is 2 - 3 times as long
  • adjustable knives by means of serration between knive and support plate; 5 adjustments of 1,6 mm = 8 mm sharpening area

Notes

  • from safety reasons please always mount knives and support plates with equal weight (packing unit VE) opposite each other

Table- and picture caption ...

B
[mm] 		H
[mm] 		S
[mm] 		PU
[pc.] 		Ident-No. Comp./ Inqu.

Dimensions entered are not listed?
Please contact our application consulting.

available from stock
available on short notice
Delivery time on request

310 38 10 2 181974
|
